EG-SG COMPACT TURNSTILE

Elegant, compact and sophisticated.
Technology and security in one solution.

EG-SG COMPACT is the compact version of the EG-SG lathe. Extensive customization options, versions for one or two leaves, and abundant configurations to suit any environment con espacio reducido.

Construction in steel, magnetic motor, operation electronic and bidirectional, possibility of integrating proximity devices and complete set of high security sensors.

  • 2 years warranty.
  • Suitable for indoor and outdoor use
Categories: , Product ID: 11607

Description

EG-SPD/SPDR turnstile in its straight and curved versions of elegant and sober design, is the top level for any access control that requires a premium image. A multitude of finishes, extensive customization options, single or double-leaf versions and plenty of configurations to suit any passageway needs, are the calling cards of a corridor that will meet your project requirements. Always with European manufacturing, steel construction, possibility of integrating proximity devices, complete set of high security sensors… All these characteristics make it ideal for absorbing a large flow of traffic.

Its engine, with patented magnetic technology, prevents friction and increases service life up to 4 times longer than its direct competitors. It has a 2-year warranty.

Additional information

Dimensions

• Height: 990 mm.
– Length: 1000 mm.
– Ancho: 120 mm.
– Glass barrier height: 835 mm.
– Passage width: 650 – 950 mm. (990 mm double-leaf version).

Standard equipment

• Emergency mode: automatic opening of the exit direction.
• Fail Safe: safety unlocking due to power failure.
– Communication interface ID systems: USB, ethernet, RS 485.
• Fully electronic and bidirectional operation.
– Power input 13.8 V DC. Opcional 24/230 V AC.

Materials and finishes

– Cabinet and base: AISI 304 brushed steel.
• Top cover: black glass (standard).
• Glass panel: 10 mm tempered safety glass.
– Optional surface finishes: RAL and metallic colors (bronze, gold and silver)

Options and accessories

• Signaling equipment.
• Slot for proximity reader integration.
– Remote control. Button panel or touch screen.
– Illumination of the glass passage leaf. LED frame.
– Supercapacitor. Feeding in case of emergency.

Security

• Detection of passage of more than one person.
• Anti-fraud by overpass or underpass.
– Electronic control to set the level of security against unwanted passage (RFID).
– Up to 24 pairs of IR sensors.
