TRIPOD T-HS
TRIPOD T-HS
- Product ID: 46396
- Category: Access Control
Single-arm turnstile.
Magnetic Direct Drive motor.
TRIPOD T-HS revolutionizes the market by introducing a new concept that prioritizes comfort, speed, and design with a lower technological impact. It features a motor with a patented direct magnetic drive technology without clutches, allowing for millions of passes. European manufacturing and maximum quality enable silent operation, requires no maintenance, resistance to extreme temperatures, and a longer lifespan than its direct high-end competitors.
- 2 years warranty
- Suitable for indoor and outdoor use
Customizable LED lights. Integrated card collector. No maintenance required. Endless finishes and colors. Fingerprint and facial recognition. European factory. Turnkey. Ebeans sensors detect thin legs. Panic system with automatic opening. Sales policy the architect is protected.
| Dimensions | • Height: 990 mm.<br />• Length: 990 mm.<br />• Width: 210 mm.<br />• Passage width: 570 mm. (max.) |
|---|---|
| Standard equipment | • Advanced Direct Drive (MDD) magnetic direct drive system.<br />• Magnetic tooth brake.<br />• Optical sensors.<br />• Panic system with automatic reset.<br />• Communication interface for various identification systems. Input / Output: RS485 / Ethernet / USB / Others.<br />• Power input (low voltage) 13.8 V DC. Optional: 24/230 V AC. |
| Materials and finishes | • Cabinet: polished AISI 304 stainless steel.<br />• Top cover: polished AISI 304 stainless steel.<br />• Arm: polished stainless steel tube with a diameter of 40 mm.<br />• Optional surface finishes (polished, satin stainless steel / blackened steel / bronze / etc.). |
| Options and accessories | • Signaling equipment.<br />• Integrated reader support.<br />• Access Light (mounted on the top cover).<br />• Remote control panel or touchscreen. |
| Security | • Individual passage detection sensors.<br />• Anti-fraud at the top and bottom. |
Downloads
-
Download: T-HS_tripod_datasheet
