Qualica-RD PERSEI TRIPOD
Qualica-RD PERSEI TRIPOD
- Product ID: 45936
- Category: Access Control
Black titanium and stainless steel tripod
Qualica-RD PERSEI is one of the most silent and robust bidirectional tripods on the market, due to a technology that guarantees an average of 10 million steps without impact on the “brushless” mechanics. It has a arched shape, which makes it unique.
The performance rate in single passage mode is 35 to 40 people per minute. It can be adjusted to single direction and bidirectional.
Suitable for all types of weather and environments, it can be applied both indoors and outdoors, such as; parks, gyms, and offices.
- 3 years warranty
Image Gallery
Qualica-RD PERSEI TRIPOD
| Body material | Stainless steel 304 + black titanium |
|---|---|
| Material of the arms | Stainless steel |
| Dimensions | 1400 * 280 * 1000mm |
| Net weight | 60kg / unit |
| Step width | 550mm (Arm length: 500mm) |
| Direction of passage | Unidirectional / Bidirectional |
| MCBF | 10 million |
| Power supply | AC220V/110V, 50/60Hz |
| Operating voltage | 24V DC |
| Electric consumption | 20W |
| Operating temperature | -20 °C – 75 °C<br>0 ~ 95% (No freezing) |
| Working environment | Interior / Exterior |
| Flow | 35-40 people per minute |
| LED indicator | Sí |
| Emergency | Automatic arm opening when turned off |
| Communication | Dry contact, relay signal, RS485 |
Downloads
-
Download technical sheet: Qualica-RD PERSEI_turnstile
