Description
Qualica-RD SUN QR411 BLACK Full Height Turnstile
Image gallery
Qualica-RD SUN QR411-B
Turnstile with special varnish for quality and elegance.
Qualica-RD SUN QR411 BLACK-BLUE is a high-tech full-height turnstile, incorporating a solid rain protection roof. Designed for both indoor and outdoor use. Varnished in black or blue. Stainless steel body, waterproof and durable. Standard dimension of 1.5m x 1.5m.
This lathe can be adapted and customized according to the customer’s needs. The mechanism is equipped with a self-regulating hydraulic damping device. There is no noise and no impact during operation.
Ideal for high security areas such as embassies, stadiums, banks, oil fields, construction sites, stations, etc.
- 3 years warranty
Additional information
| Material de la estructura y color | Acero + barniz al horno Color: Negro o azul |
|---|---|
| Soporte del brazo | Rotores de 120° con 3 secciones o rotores de 90° con 4 secciones |
| Dimensiones | 1500 * 1500 * 2250mm |
| Peso neto | 260kg/unidad |
| Ancho de paso | 1 carril, 650mm/carril |
| Dirección de paso | Monodireccional y Bidireccional |
| MCBF | 5 millones |
| Suministro de energía | AC220V/110V, 50/60Hz |
| Tensión de funcionamiento | 24V DC |
| Consumo de energía | 40W |
| Temperatura de funcionamiento | -15 °C – 60 °C |
| Humedad de funcionamiento | 0 ~ 95% (sin congelación) |
| Comunicación | Contacto seco, señal de relé, RS485 |
| Entorno de trabajo | Interior / Exterior |
| Caudal | 35-40 personas por minuto |
| Indicador LED | Sí |
| Emergencia | Apertura automática del brazo cuando se corta la corriente |
Downloads
-
Download datasheet: Qualica-RD SUN QR411-B_full_height_turnstile
